Samsung 970 EVO PLUS M.2
Stock Code:
MZ-V7S1T0BW
Stock Code:
MZ-V7S250BW
Stock Code:
MZ-V7S500BW
$220.00 (inc GST)
$93.50 (inc GST)
$121.00 (inc GST)
Description
Samsung 970 EVO PLUS M.2
Samsung Always Evolving SSD
970 EVO Plus NVMe M.2 SSD 250GB
- Samsung’s latest V-NAND technology
- Dynamic Thermal Guard
- Intelligent TurboWrite
The ultimate in performance, upgraded. Faster than the 970 EVO, the 970 EVO Plus is powered by Samsung’s latest V-NAND technology and firmware optimization. It maximizes the potential of NVMe bandwidth for superb computing. In capacities up to 2TB, with reliability of up to 1,200 TBW1.
The 970 EVO Plus can reach sequential read/write speeds up to 3,500/3,300 MB/s2, up to 57%3 faster than the 970 EVO. Samsung’s latest V-NAND—which brings greater NAND performance and higher power efficiency—along with optimized firmware, a proven Phoenix controller, and Intelligent TurboWrite boost speeds.
The next advancement in NVMe SSD. The 970 EVO Plus fits up to 2TB onto the compact M.2 (2280) form factor, greatly expanding storage capacity and saving space for other components. Samsung†s innovative technology empowers you with the capacity to do more and accomplish more.
The new standard in sustainable performance. Get up to 1,200 TBW4 with a 5-year limited warranty for lasting performance. The 970 EVO Plus provides exceptional endurance powered by the latest V-NAND technology and Samsung’s quality.
Achieve a new level of drive confidence. Samsung’s advanced nickel-coated controller and heat spreader on the 970 EVO Plus enable remarkable heat dissipation. The Dynamic Thermal Guard automatically monitors and maintains optimal operating temperatures to help minimize performance drops.
Samsung Magician
Advanced drive management made simple. The Samsung Magician software will help you keep an eye on your drive. A suite of user-friendly tools helps keep your drive up to date, monitor drive health and speed, and even boost performance.
For more information, Click Here>
Samsung 970 EVO PLUS M.2 500GB MLC V-NAND 3-bit MLC 3,500MB/s 2,300MB/s, 370K/500K IOPS, 150TBW 5 Years Warranty
Application
- Client Workstations/PCs
Capacity
- 250GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise)
Form Factor
- M.2 (2280)
Interface
- PCIe Gen 3.0 x 4, NVMe 1.3
Dimensions
80.15 x 22.15 x 2.38 (mm) (WxHxD)
Weight
Max 8.0 g Weight
Storage Memory
Samsung V-NAND 3-bit MLC
Controller
Samsung Phoenix Controller
Cache Memory
Samsung 512MB Low Power DDR4 SDRAM
Special Features
TRIM Support
Supported
S.M.A.R.T Support
Supported
GC (Garbage Collection)
Auto Garbage Collection Algorithm
Encryption Support
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive)
WWN Support
Not supported
Device Sleep Mode Support
Yes
Performance
Sequential Read
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration
Sequential Write
Up to 2,300 MB/s * Performance may vary based on system hardware & configuration
Random Read (4KB, QD32)
Up to 250,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD32)
Up to 550,000 IOPS * Performance may vary based on system hardware & configuration
Random Read (4KB, QD1)
Up to 17,000 IOPS * Performance may vary based on system hardware & configuration
Random Write (4KB, QD1)
Up to 60,000 IOPS * Performance may vary based on system hardware & configuration
Environment
Average Power Consumption (system level)
* Average: 5 W * Maximum: 8 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration
Power consumption (Idle)
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration
Allowable Voltage
3.3 V ± 5 % Allowable voltage
Reliability (MTBF)
1.5 Million Hours Reliability (MTBF)
Operating Temperature
0 - 70 C Operating Temperature
Shock
1,500 G & 0.5 ms (Half sine)
Software
Management SW
Magician Software for SSD management
Warranty
5-Year Limited Warrantyor 150 TBW Limited Warranty
