iQ-WEBX WADO
Stock Code:
IQ-WEBX WADO HL-7
Stock Code:
IQ-WEBX WADO
POA
POA
Downloads
Description
iQ-WEBX WADO
iQ-WEBX WADO provides quick and easy access to imaging studies and reports from any HIS, PMS or EMR.
The benefits for radiologists in having all digitized imaging data available online are obvious. However, referring physicians, such as traumatologists, orthopaedic surgeons or internal specialists in both hospitals and ambulant patient care often do not have immediate access to the required medical images. iQ-WEBX WADO is the solution for easy image access integrated into any hospital information system (HIS), practice management system (PMS) or Electronic Medical Record (EMR).
How does it work? iQ-WEBX WADO provides a secure web-based interface, integrating iQ-WEB into other web-based or thick client based medical information systems. Referring physicians can easily access images and reports via this interface using the login of their existing information system - without having to log in once again. An automatic authentication process ensures the accurate access from virtually any other medical information system.
The settings of iQ-WEBX WADO are exclusively specified within the web browser. The administrator can choose between either a conventional view of imaging or a presentation of the results in the iQ-4VIEW or iQ-X viewers with many additional image processing tools. Any iQ-WEBX user can automatically authenticate on iQ-WEBX WADO. The configured iQ-WEBX user account also specifies the rights which the user has while directly opening images. A 128 bit AES encryption guarantees high data security.
iQ-WEBX WADO Features*
GENERAL
- Configuration embedded in the iQ-WEB administration web interface
- Study/image evaluation via direct call into a viewer
- Temporary or permanent external diagnostic access to selected studies via WADO links (NEW!)
ACCESS
- Single Sign On using predefined login data for automatic authentication (no need to log in twice)
- Customizable duration of PACS access
SUPPORTED CALLS
Lists all studies/images depending on transmitted identifier:
- Patient IDs
- Accession numbers
- Study instance UIDs
- Series instance UIDs
- Patient names
- Access to patients studies by BDT/GDT file
- Viewer option allows opening in either:
- iQ-X
- iQ-4VIEW
- iQ-VIEW**
- Simple web image view in JPEG quality
- Browser-dependent opening of viewer
- WADO links can be used on mobile devices (using iQ-WEB2GO) if viewer mode is set to "iQ-4VIEW" or "simple web image view"
- HL7 support on request
- ORM messages (orders)
- ORU messages (report + URL)
SECURITY
- Higher security by optional AES encrypted WADO IDs (NEW!)
- Compliant with US and European data protection laws and regulations
iQ-WEBX WADO HL7 Features
CPOE (Computerized Physician Order Entry) compliant feature that integrates studies with any HIS, RIS or information system. iQ-WEBX WADO HL7 receives order request messages from the HIS/EMR and forwards them to the Worklist Server where they are retained while waiting for a query from the modalities. The modalities receive the procedure and patient data from the Worklist Server and send the acquired images to the PACS Server once the procedure has been performed. iQ-WEBX WADO HL7 queries the PACS Server and generates a web link to easily access the study once it is available.
Please note that an iQ-WORKLIST license is required for the use of iQ-WEBX WADO HL7.
* Detailed information on iQ-WEBX WADO’s system requirements is available in the iQ-WEBX WADO Instructions for Use and Administration Guide or the iQ-SYSTEM PACS Hardware Purchasing Guide.
** via iQ-VIEW Call
IQ-WEBX WADO
Trial license: time-limited (30 days trial period)
Warranty: 1 year limited warranty
Activation method: license file per server
Languages: English
Annual Service Package: mandatory (see Warranty and Service Packages for details)
IQ-WEBX WADO HL7
Warranty: 1 year limited warranty
Activation method: Installation by one of IMAGE’s engineers
Languages: English
Annual Service Package: mandatory (see Warranty and Service Packages for details)
Please note that an iQ-WORKLIST license is required for the use of iQ-WEBX WADO HL7.
