iQ-VIEW VET
Stock Code:
IQ-VIEW-VET-BASIC
Stock Code:
IQ-VIEW-VET-PRO
POA
POA
Description
IQ-VIEW VET
Veterinary Radiology Workstation Software
IQ-VIEW VET is an easy-to-use reading station, specialized for veterinarians. A customized veterinary graphical user interface and the especially adapted text overlay are only some of the many veterinary features. All important veterinary data, like breed description or studbook name, is visible on every image, thus providing easy patient recognition.
IQ-VIEW VET is available in two different versions: BASIC and PRO. The BASIC version includes all required features for viewing and reading while the PRO version offers professional tools for reading specialists like presentation states and individually customizable hanging protocols. Hanging Protocols make it easy to view for instance pre-purchase examinations of horses for facilities dealing with equine patients. Studies and images can be loaded automatically as each veterinarian wishes to read them.
Vet-specific measurements, such as the Norberg angle, make image review simple and fast.
iQ-VIEW VET can be integrated into virtually any RIS, EMR or HIS available on today's market. Additional modules for 3D post-processing, nuclear medicine, orthopaedic templating, image stitching and more equip specialty readers with the required tools. iQ-VIEW VET is a fast and powerful reading station, which includes many additional useful features, such as a basic structured reporting module. It is also ideal for teleradiology purposes - encrypted DICOM email makes it possible.
Main Features:
- iQ-VIEW VET is an easy-to-use reading station
- Veterinary specific DICOM support
- CD/DVD Burning
- DICOM Images
- JPG Images
- Email of images
- Lite Viewer with DICOM Images exported to CD/USB
IQ-VIEW VET
IQ-VIEW VET Basic Features
General:
- Support for Windows 7, Windows 10
- Scalable buttons and possibility to set font size (for high-resolution displays)
- Multimonitor support
Study Browser:
- Study table
- Thumbnail preview
- Virtual patient root model
Viewer:
- Veterinary text overlay
- Image processing (including comparison of multiple studies, image filters and
- synchronization/desynchronization of series)
- Configurable bottom toolbar and creation of viewer shortcuts
- Measurements (including distance, angle, Cobb angle, Norberg angle, ROI,
- modify/delete options)
- Basic annotation of images (incl. Secondary Capture image creation)
- DICOM presentation states on image level
- Configurable scoutlines to display plane projections and/or plane intersections
- Integration of 3rd party image processing
Reporting:
- Structured reporting module with read/write/edit support of Basic SR objects
- Read-only support for other SR formats
Import:
- Lists containing veterinary body parts and image views
- Additional veterinary DICOM information included, e.g. studbook, breed, species or
- owner information, sex neutered and more
- TWAIN interface (scanner, video capture and CR)
- Drop box interface for automatic image file import
- Image file import (BMP, JPEG, TIFF, RAW)
- Patient CD/DVD/USB import
Export:
- Patient CD/DVD/USB
- Integration of direct interface to iQ-ROBOT module for patient CD/DVD creation and
- label printing (not available in the USA)
- Image export to image file or AVI video file (including measurements, windowing,
- color remapping, annotations and more)
- Sending of JPEG images by email
Printing:
- Print to DICOM imagers of any brand
- Windows® print
- True-size (1:1) DICOM printing
Communication:
- Server administration tool for easy configuration
- Smooth interoperability with iQ-products; support of various transfer syntaxes
- HIS/PMS interface (accession number or GDT/BDT) (others on request)
- DICOM Query/Retrieve, C-FIND, C-STORE, DICOM print client and DICOM email
Add-Ons:
- Optional 3D post-processing add-on module (iQ-3D)
- Optional image stitching software (iQ-STITCH)
- Optional orthopedic templating module (OrthoViewTM)
- Optional nuclear image processing (iQ-NUC)
Licensing:
- Single (PC-based) or concurrent (floating user) licenses
Languages:
- English, French, German
IQ-VIEW VET Pro Features
Viewer:
- Hanging Protocols (including the creation of HP sequences and modality-specific toolbars)
- Perpendicular distance, polygonal ROI
- Copy of measurements to other images to enable 3D measurements
- Dynamic magnifier window for seamless image zooming
- Annotation of images (incl. storing and sending as Presentation States)
- Color schemes for nuclear medicine, e.g. GE Color, Hot Iron, Lut7
Communication:
- DICOM Worklist Client
Import:
- Video capture interface (DirectShow®)*
- Foot switch support
- VET-CR ACE post-processing incl. histogram function and S-value (optional)
