Eizo Radiforce RX370 21" 3MP LED Medical Colour Monitor
Stock Code:
RX370
POA
Description
RadiForce RX370 Diagnostic Monitor
A 3 megapixel high-brightness monitor ideal for accurate display of monochrome and color images.
Evolve Your Image Reading
As more image modalities become digitalized, radiologists are viewing an increasing amount of information on their screens. EIZO's unique Work-and-Flow technology alleviates the complexity of the imaging workflow with new functions developed with the radiologist in mind. Users can take advantage of Work-and-Flow functions with the RadiForce monitor and bundled RadiCS LE software.
Boost Images for Easy Viewing
The Instant Backlight Booster function temporarily maxes the brightness of the monitor for quickly making detailed medical images easier to see. A single hotkey allows users to turn the function on for multiple monitors at once so they can easily view more than one screen under the same high-brightness conditions.
Barrier Free Work style
With the Switch-and-Go function, you can operate two different workstations at the same time with a single mouse and keyboard. Work across several monitors by moving the mouse from one screen to the other or switch the signals between workstations as needed without having to change your mouse and keyboard each time. This makes it possible. To reduce the number of monitors in the work flow and improves work efficiency.
High Fidelity Images for Peace of Mind
Display Both Monochrome and Color
The Hybrid Gamma PXL function automatically distinguishes between monochrome and color images pixel by pixel, creating a hybrid display where each pixel has optimum grayscale.
As a result, monochrome images such as CR and DR are displayed in the ideal grayscale that corresponds to DICOM Part 14, while color images such as those used in endoscopy, nuclear medicine, 3D rendering, and fusion imaging are faithfully reproduced corresponding to Gamma 2.2. This improves the efficiency of viewing both monochrome and color images together on one screen.
Achieve Clarity True to the Source Data
A medical monitor needs to be capable of high brightness in order to meet performance standards. However, in order to achieve high brightness in an LCD panel, the pixel aperture ratio has to be increased. This causes a typically unavoidable decline in sharpness. With EIZO's unique Sharpness Recovery technology, the decrease in sharpness (MTF) is restored. This allows you to display an image that is true to the original source data safely on the monitor, even at high brightness levels.
MTF measures numerically how faithfully the panel transfers details from the original image data for viewing. When Sharpness Recovery is turned on, in the case of a 2 pixel line pair (spatial frequency of 1.182 cycles/mm) the MTF increases by approximately over 50%.
Make the Precise Diagnosis
EIZO carefully measures and sets the grayscale at the factory to ensure each monitor is compliant with DICOM Part 14. Furthermore, at startup or upon wakeup, the EIZO patented drift correction function quickly stabilizes the brightness level and compensates the brightness fluctuations caused by the ambient temperature and the passage of time, allowing medical images to be faithfully reproduced with stable brightness and grayscale.
Convenient Connectivity for Comfortable Use
Hassle-Free Multi-Monitor Configuration
Using the DisplayPort connection, you can drive several monitors in a daisy chain sequence. This allows you to configure a multi-monitor setup without the complicated hassle of excessive cabling.
Elegant Cabinet Design
The black front bezels are ideal for viewing the screen in dark reading rooms, making it easier to focus on images, while the original white stripe around the sides and curves on the back present an elegant and clean aesthetic.
USB Hub and USB Type-C for Charging
The monitor is equipped with two USB Type-A downstream ports for connecting a mouse, keyboard, or other USB devices. It is also equipped with a USB Type-C port with up to 15 watt power supply for charging smartphones and tablets. The USB Type-C port does not allow the computer to access the device's memory or settings, so you can rest assured that it remains secure while connected.
Rest Assured with Image Consistency
Maintain Image Quality Over Time
An LCD monitor's color and brightness characteristics naturally shift with use over time. Since this occurs gradually, it can be difficult to detect when this happens. Implementing a quality control solution ensures that your monitor's display characteristics stay consistent.
With the Integrated Front Sensor (IFS) built into the front bezel of the RadiForce monitor and RadiCS LE software (included) , you can easily calibrate to DICOM Part 14 without having to mount, run, and remove an external sensor.
Stay Confident with Stable Brightness
EIZO's confidence in its product quality extends to brightness stability which is also covered during the usage time specified in the warranty.
Warranty with Safety and Trust
Click here for Warranty Information
RadiForce RX370 Diagnostic Monitor
Model Variations
RX370-BK: Anti-Glare coating, with stand, black
RX370-ARBK: Anti-Reflection coating, with stand, black
Panel
Type: Colour (IPS)
Backlight: LED
Size: 54.1 cm / 21.3"
Native Resolution: 1536 x 2048 (3:4 aspect ratio)
Viewable Image Size (H x V): 324.9 x 433.2 mm
Pixel Pitch: 0.2115 x 0.2115 mm
Display Colours 10-bit (DisplayPort):
10-bit (DisplayPort): 1.07 billion from a palette of 543 billion (13-bit) colors
8-bit: 16.77 million from a palette of 543 billion (13-bit) colors
Viewing Angles (H / V, typical): 178° / 178°
Brightness (typical): 1100 cd/m2
Recommended Brightness for Calibration: 500 cd/m2
Contrast Ratio (typical): 1800:1
Response Time (typical): 25 ms (black-white-black)
Video Signals
Input Terminals: DisplayPort x 2, DVI-D (dual link)
Output Terminals: DisplayPort (daisy chain)
Digital Scanning Frequency (H / V): 31 - 127 kHz / 29 - 61.5 Hz
USB
Upstream USB: 2.0: Type-B x 2
Downstream USB 2.0: Type-A x 2
Dedicated Charging Port: USB Type-C (Power Supply 15 W max.)
Power
Power Requirements: AC 100 - 240 V: 50 / 60 Hz
Typical Power Consumption: 36 W
Maximum Power Consumption: 105 W
Power Save Mode: 1 W or less
Sensor
Backlight Sensor, Integrated Front Sensor, Presence Sensor, Ambient Light Sensor
Features & Functions
Brightness Stabilization: Yes
Digital Uniformity Equalizer: Yes
Hybrid Gamma PXL: Yes
Work-and-Flow: Hide-and-Seek, Switch-and-Go, Point-and-Focus, Instant Backlight Booster
Preset Modes: CAL Switch (DICOM, CAL1, CAL2, Custom, sRGB, Text)
OSD Languages: English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese
Physical Specifications
Net Weight: 8 kg
Net Weight (Without Stand): 5.2 kg
Hole Spacing (VESA Standard): 100 x 100 mm
Certifications & Standards
(Please contact EIZO for the latest information.)
CE (Medical Device), EN60601-1, ANSI/AAMI ES60601-1, CSA C22.2 No. 601-1, IEC60601-1, VCCI-B, FCC-B, CAN ICES-3 (B), RCM, RoHS, China RoHS, WEEE, CCC, EAC
Approvals
FDA: 510(k) Clearance for General Radiography
TGA: Class I Medical Device, Primary Reporting
Dedicated Software
Monitor Quality Control Software RadiCS: Supported
Supplied Accessories
(May vary by country. Please contact EIZO for details.)
Signal Cables: DisplayPort (3 m) x 2
Others: AC power cord (3 m), USB Type-A - USB Type-B cable (3 m) x 2, Utility Disk (RadiCS LE, PDF instructions for use, PDF installation manual), instructions for use
